MacPherson strut suspension in cars: A Comprehensive Guide

Posted on: Jan 17, 2025 | 3 mins | Written by: HDFC ERGO Team

MacPherson strut suspension in cars: A Comprehensive Guide

MacPherson strut suspension system is one of the most common forms of suspension systems in contemporary vehicles. It has derived its name from the famous American car engineer Earle S MacPherson. Due to its simple design and budget-friendly manufacturing costs, this form of suspension system has gained rapid popularity.

This is a typical form of independent suspension system in cars, located on the front axle of the vehicle. It deftly replaces the steering rod, while acting as an able suspension and vibration dampener together.

It possesses a considerable compression link or a wishbone, which remains balanced with the help of another additional link, which in turn, serves as the mounting point in the bottom for the wheel’s axle or hub.

This special design of the lower arm places the wheel both vertically and horizontally.

In this article, we will highlight all the significant aspects of MacPherson strut suspension in cars.

What are the benefits of MacPherson strut suspension in cars?

MacPherson strut suspension in cars is composed of 4 major components:

1. Strut assembly:

This is a special and clever combination of shock absorbers and coil springs and forms the principal structural element of this system. This component remains responsible for enduring the weight of the car along with the road impacts.

2. Control arm:

This arm is also known as the wishbone or A-arm, which links the steering knuckle with the body of the vehicle. This aids in controlling the assembly motion of the wheel.

3. Steering knuckle:

This is a significant component that links the strut assembly of the vehicle to the wheel hub, allowing smooth steering movement.

4. Sway bar:

Also known as the anti-roll bar, it reduces the body roll during the cornering of the vehicle. It efficiently connects the suspension components to the vehicle’s sides.

Made of these 4 components, some of the most significant benefits of MacPherson strut suspension include the following:

1. Easy maintenance and manufacturing:

When compared to other suspension systems, this system consists of fewer components, resulting in easy maintenance and manufacturing.

2. Budget-friendly production:

As the design of this suspension system is simple, the production and repair costs are also comparatively lower.

3. Space efficiency:

This system has a typically small footprint, allowing effective space usage. This makes it ideal for small and compact vehicles.

Despite so many advantages, MacPherson strut suspension has certain disadvantages too:

1. Space:

The MacPherson strut suspension system requires a very strong top mount along with an enhanced vertical space.

2. Restricted vertical wheel movement:

Considering the geometrical analyses, this suspension system does not allow vertical wheel movement without a certain degree of change in the camber angle or sideways movement.

3. Handling:

This sort of suspension affects the handling of the vehicle to a certain extent, offering a minimal opportunity for camber change or choosing the roll centre.

4. Noise and vibration:

MacPherson strut suspension systems in cars tend to produce more vibration and noise than other forms of suspension systems.

How does MacPherson strut suspension in cars work?

The working strategy of the MacPherson strut suspension system in cars is simple. It works as follows:

1. Absorption:

The simple construction technique of this sort of suspension system is composed of a coil spring and a damper. This spring remains attached to the system for effective shock absorption caused by any sudden jerk on uneven terrains.

2. Hydraulic fluid:

After this, the shock absorber utilises hydraulic fluid to release the heat created by this shock energy.

3. Effective restrainment:

Any undesirable movements of the car caused by improper road conditions get efficiently restrained when both these components function well in sync in this form of suspension.

To ensure the smooth functioning of this suspension system, you need to follow these few simple tips:

1. Check:

You can check the components of your vehicle’s suspension system through close and frequent monitoring. If your vehicle shows any symptoms of leakage, sagging of coil springs, damage of the arm springs or any issues with the sway bar, you must address the issues without any delay.

2. Replacement:

To enjoy optimum service and performance, repair and replace all the damaged and worn-out components without any delay.

3. Balance and rotation:

To ensure even wear and extend the life of the tyres, try to balance and rotate them at regular intervals.

4. Wheel alignments:

To enjoy maximum steering performance, perform the necessary wheel alignments.

With time and technological advancements, several improvisations and innovations can be observed in the suspension systems:

1. Active suspension:

You can adjust the suspension system in real time with the aid of several electronic sensors and various actuators. Therefore, you can enjoy maximum stability, riding comfort, and easy handling.

2. Lightweight designs:

The advanced inventive designs contribute to improved vehicle efficiency and improved range which effectively lowers the weight of suspension without compromising on the performance.

3. Adaptive damping technologies:

Be it magnetorheological controlled or electronic damper, these advanced forms are gaining rapid popularity. They can effectively adjust the damping characteristics considering the driving circumstances. This ensures a comfortable driving experience with deft precision and handling.

Conclusion

The suspension systems have evolved significantly over time. The MacPherson strut suspension is the latest and the most popular addition to this family. However, irrespective of these advancements, if you own a four-wheeler, you must ensure to retain an active and valid car insurance policy. It can be a simple third-party car insurance plan or a more elaborate comprehensive car insurance policy.
