What Are V Engines and Their Types?

An automobile engine's primary function is converting heat energy to mechanical power to make the car run. This power generation produces torque, eventually transmitting it to the wheel. However, depending on the mechanism and style of the concerned vehicle, the combustion engine type may vary. Among such variants, the V-type engines are regarded as the most efficient. They effortlessly create rotational power.

However, irrespective of the engine mechanism, you must maintain a four-wheeler insurance policy to meet the legal standards. It can be a basic third-party or more elaborate comprehensive car insurance policy.

What is a V engine?

This is a popular combustion engine, inside which dual cylinders remain connected over the concerned crankshaft, usually at an angle of 60-90 degrees. This typical angle formation gives it the appearance of a V. Such angular placement enhances the overall efficiency of the engine.

Working strategy of a V engine

In V-type engine cars, the cylinders draw in air and fuel inside the chambers, which are then compressed and ignited to make the vehicle run. The combustion in the compressed chambers creates enormous pressure and the power shifts to the pistons forcing them to move down. These pistons release the stored gas and move upward again. This is a cycle that repeats forcing the vehicle to run.

Types of V-engine

The V-engine types can be classified into several categories depending on their mechanisms. Some of the most significant V-type engines include the following:

1. V2 engine:

Also termed a V-twin cylinder, this variant utilizes dual-cylinder chambers. As they need comparatively less space to fit, they are often considered a suitable fit for two-wheelers, especially bikes. This mechanism was first utilised back in 1889 in the vehicles of Daimler Strahlradwagen.

2. V4 engine:

This sort of engine maintains a comparatively complicated mechanism because of which it is rarely used in vehicles. As the name suggests, this engine variant uses 4 cylindrical chambers, situated at 90 degrees to ensure enhanced performance. However, the involvement of too many components makes it all the more complex.

3. V6 engine:

This is the commonest form of engine variant which includes 6-cylinder chambers. 2 sets, each of 3 cylinders remain interconnected with each other maintaining an angle of either 60, 90, or 120 degrees. These engine variants are comparatively shorter, lighter and compact, offering enhanced fuel efficiency.

4. V8 engine:

This is one of the most used and convenient layouts of the engine. It was first introduced back in 1903, post the successful implementation of the V2 engines. 2 sets of 4 cylinders remain fixed at an angle of 90 degrees with the help of a crankshaft. This rigid engine is quite noted for its immense combustion capacity.

5. V10 engine:

This sort of engine consists of a 10-cylinder piston, and 2 sets of 5-cylinders each remaining fixed in a V formation around the crankshaft. This sort of engine is by far the least popular variant as compared to the V6, V8, or V12 models. Multiple V10 diesel engines have been produced since 1965. However, with the launch of the Dodge Viper in 1991, the V10 petrol model was first introduced in road vehicles.

6. V12 engine:

Last but not least, V12 engine model consists of 12-cylinder chambers. These are especially noted for their highest horsepower-generating capacity. These are mostly used in high-capacity vehicles like ships, aircraft, military vehicles, etc. Here, 2 sets of 6 cylinders remain positioned at a 60-degree angle. This type of engine was first introduced in the Rolls Royce Phantom III model.

Applications of V engines

This table highlights the respective uses and utilities of every V-engine type:

V-ENGINE TYPES	APPLICATIONS
V2	This sort of compact engine is usually used in high-end motorbikes like sports bikes and cruisers. However, certain small cars also use this sort of engine.
V4	This sort of engine is usually used in marine outboards. However, certain MotoGP manufacturers also use it.
V6	Some of the common vehicles where this type of V engine is used include racing cars, marine outboards, railway engines, etc.
V8	This is mostly used in luxury vehicles, SUVs, sports cars, and pickup trucks.
V10	Used in high-performance vehicles like RS6 Audi, Audi R8, BMW M5, BMW M6, etc. Volkswagen has also introduced a V10 engine in its turbo-diesel model.
V12	Can only be found in high-end vehicles like the Ferrari 812 GTS, Mercedes Benz S Class, and Lamborghini Aventador, because of their heavy manufacturing costs

V engine components

Some of the significant components of V-engine vehicles include the following:

• Camshaft

• Injector rocker arm

• Injector control shaft

• Injector rack

• Fuel Injector

• Water inlet jumper

• Exhaust valve

• Piston

• Cylinder head

• Cylinder liner

• Crankcases

• Oil level gauge and oil pan

• Piston cooling oil pipe

Advantages of the V engine

Some of the most highlighting advantages of the V engine are as follows:

1. Size:

V engines are available in multiple size variants ranging between 2 and 24 cylinders.

2. Weight:

V engines are comparatively smaller in size and lightweight than inline engines.

3. Performance:

V-type engine cars exhibit a far more enhanced performance rate than inline engine vehicles.

4. Noise:

The V-type engine cars produce comparatively much lesser vibration and noise.

5. Power transfer:

The V engines require more pistons which eventually enhances the power transfer procedure to the crankshaft.

Disadvantages of V engine

Despite so many benefits, V engines have certain typical disadvantages too:

1. Complicated structure:

The V engine structure mechanism is comparatively far more complicated than inline engines, eventually raising the servicing and manufacturing prices.

2. Stress:

The V-engine car drivers may face disturbing issues like mechanical stress and vibration if there is even a slight imbalance in the V-engine installation.

3. Fuel consumption:

The fuel consumption in V-type engines is comparatively higher than inline engines.

4. Maintenance cost:

The maintenance cost of V-engines is comparatively much higher than other engine variants.

Conclusion

To cut the long story short, we can summarise that a V-type engine is an efficient and compact power-generating tool involving complicated mechanisms to produce power in high-end vehicles. It efficiently generates high power and the acceleration procedure is also comparatively faster. There are several variants in types of V engines depending on the total number of cylinders present which classifies them into different categories.

FAQs

Q. What is the basic difference between a V-type engine and an inline engine?

A: All the cylinders present in an inline engine are positioned vertically facing upwards. Usually, the number of cylinders present is in odd numbers.
